2.Name:3-Way GPS&GLONASS Active Splitter
3.Specification:
|
Frequency Range(MHz) |
1100-1700 |
|
Gain(dB) |
8±2.0 |
|
Noise Figure(dB) |
1.5dB (typical) @ |
|
Isolation(dB) |
≥20 |
|
VSWR |
Input: ≤2.0:1 |
|
Output: ≤1.5:1 |
|
|
Amplitude Balance(dB) |
/ |
|
Impedance(Ω) |
50 |
|
DC PASS(V) |
3-5 |
|
Operating current(mA) |
≤50 |
|
Connectors |
TNC/N/SMA |
|
Power Rating(dBm) |
25 |
|
Temperature(°C) |
-30~+70 |
|
Size(mm) |
72×53×21.5(including connectors) |
|
Mounting Holes |
2holes, |
|
Weight(kg) |
0.35 |
